AVERMEDIA D315AOP 5G 32GB AGX ORIN SYSTEM

Home > Embedded Systems > AVerMedia >

Alternative Views:

If you are a company within the EU other than Ireland, please provide your VAT number, preceded by your country code at check out and we will remove and re-fund the VAT element prior to shipping.

Also if you are a purchaser based in Norway, Switzerland or UK, we will re-fund the VAT element prior to shipping and will ship, delivery at place (DAP) and purchaser will be responsible for local taxes, duties and tariffs, if applicable.

Fanless design to prevent dust accumulation
1x M.2 B key for 4G & 5G
1x GbE & 1x 10G RJ-45
10GigE Vision camera connector
1x PCIe slot for multi-function expansion
1x M.2. E key for Wi-Fi 6E
1x M.2. M key for SSD and capture
Operating temperature D315AOP (5G) 32G: -25°C ~50°C
Operating temperature D315AOP (5G) 64G: -25°C ~40°C
Dimension (Fanless): 160*136.9*65mm
Weight: 1.55kg

For any volume quotes, please contact us on our details below:

T: +44 (0)118 981 6888
E: [email protected]

Our Price (ex VAT): €2,148.77

Product Code: 61D315AOP1BA

Qty:

Description

Features

Technical information

AVerMedia AI Box PC D315AOP 5G equips with NVIDIA Jetson AGX Orin 32GB module, which brings next-level AI performance and power-efficient capability for all autonomous machines. This efficient SoM makes advanced analytics possible while providing the ability to handle a host of other embedded IoT applications.

D315AOB 5G features a 120-pin high-speed connector designed for connecting MIPI SerDes cameras, catering to the needs of AMRs (please note that the adapter board and MIPI camera are not included). In addition, a sufficient Ethernet bandwidth with 10G is excellent for applying smart security, enabling dozens of IP cameras to stream simultaneously. The connector for the 10GigE Vision Camera is also great for smart inspection. Lastly, with its compact size, D315AOP furnishes a PCIe slot for multi-function expansion and excellent compatibility with Wi-Fi 6 and 5G.

The Embedded System that Unlocks the Full Potential of AI

Product Support

Versatile AVerMedia SDK Support

Industrial customers can develop vertical applications flexibly and efficiently by using AVerMedia’s exclusive designed SDK with features such as device control, media capture, A/V processing and more. Learn more about AVerMedia SDK.

For any support related infomation, please create a ticket via AVemedia's support page: click here
